The Zero-G has transitioned from DCT motors to RS485 motors. For additional details, please refer to our updated instructions.
Please use our screen builder or consult with your system designer for an official specification drawing. Screen materials may expand and contract slightly over time. SI allows a 1.5% tolerance within the viewing surface.
Motor
Somfy® RS485 Motor
Sizes
Min: 80″ (2032mm)
Max: 160″ (4064mm)
Available in standard sizes only. All dimensions are listed as seamless. Please go to our Screen Builder tool to see other standard sizes at https://dash.screeninnovations.com/screencalculator/Zero-G
Aspect Ratios
16:9
16:10
2.35:1
Cord Colors
White | Beige | Black | Forest Green | Gray | Sky Blue
Installation | Adjustment
Maximum drop of 7.9′ depending on screen size.
Material roll pre-installed from the factory.**
Removable upper motor lift tube with single pin release.
PCB is slide removable from the case.
Flush doors are pre-programmed from the factory.
Automatic upper limit by optical sensor.
** Applies only if case and material roll/motor assembly are shipped together (optional).
Case Specifications
Flush or external configuration.
Black or white color options for external case.
Top side recessed electrical control cable access.
Optional separated shipping for case and material roll/motor assembly.
Safety clips on external fascia.
