DT Dynamic 2S

$999.00

On wall projector screen with 2-way motorized side masking

DT 2-way side masking screens feature masking from both sides of the screen allowing the image to be perfectly masked. The range of 2-way side masking screens allow for solutions from the smallest of rooms through to the largest of auditoriums.


Build Your Screen Find Local Dealer
Call SI Support
Call
512-832-6939
M – F, 8AM – 6PM
SI Support
Support
We're here to help with any
questions or problems.
Visit Support
Contact SI Support
Contact
Email our support team with any questions or problems.
Contact Support
2-Way Side Masking

The Dynamic‑2S series supports 2-way motorized side masking allowing perfect framing of aspect ratios in the range 1.33 to 2.40:1. This variable width and constant height masking maximizes the impact of movie content.

DT Dynamic-2S-XL Closed Meeting Room
Mask Position Logic

The Mask Position Logic (MPL) system is a proprietary development of DT Screens and enables the Dynamic-2S to calculate the exact location that the masks should be positioned to create any requested aspect ratio in the supported range. With MPL, setting mask presets is no longer required.

Whispertec Motor

The proprietary Whispertec motor system runs at just 30dB which makes the Dynamic‑2S the quietest masking screen in operation.
(DT-DYN-2S, DT-DYN-2S-L only)

Size

Dynamic-2S
Width = Viewable Screen width + 15.28″ (388mm)
Height = Viewable Screen height + 15.28″ (388mm)
Max frame depth = 5.04″ (128mm)
Wall Surface to image Surface = 1.46″ (37mm)

Dynamic-2S-L
Width = Viewable Screen width + 18” (458mm)
Height = Viewable Screen height + 18” (458mm)
Max frame depth = 6.54″ (166mm)
Wall Surface to image Surface = 2.36″ (60mm)

Dynamic-2S-XL
Width = Viewable Screen width + 23.6″ (600mm)
Height = Viewable Screen height + 23.6″ (600mm)
Max frame depth = 6″ (200mm)
Wall Surface to image Surface = 3.78″ (96mm)



Color

Black Velvet

Aspect Ratios

Motorized Variable Masking – 1.33 to 2.40:1



Installation | Adjustment

Front image surface fitting – fit the frame to the wall then install the image surface



Motor

Whispertec quiet motor
(DT-DYN-2S, DT-DYN-2S-L only)



Power Type

120v or 230v

Call SI Support
Call
512-832-6939
M – F, 8AM – 6PM
SI Support
Support
We're here to help with any
questions or problems.
Visit Support
Contact SI Support
Contact
Email our support team with any questions or problems.
Contact Support
Gain ALR Acoustic Material
1.2 65 Yes Slate AT 1.2
Material
Gain ALR Acoustic Material
0.8 10 Yes ATRef
Material
Gain ALR Acoustic Material
0.7 10 Yes ATProV2
Material
